Technical Data
8-2
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Electrical Specifications
Item Data Note
Hose/gun heating capacity 2 hose/gun pairs
Control temperature range (240 and 120 VAC) 40 to 230 °C (100 to 450 °F)
Control temperature accuracy 0.5 °C ( 1 °F) A
IP rating IP 32 A
NOTE A: Flow setpoint at manifold outlet
Motor and Pump Specifications
Item Data Note
Viscosity Range
Melter with filter 1000–30000 cps.
Melter without filter 1000–10000 cps
Maximum hydraulic pressure
Melter with filter 75 bar (1100 psi)
Melter without filter 40 bar ( 600 psi)
Displacement 4.9 cc/rev or 7.8 cc/rev
Motor speed
1
/
6
hp 86 rpm at 60 Hz or 72 rpm at 50 Hz
1
/
4
hp
89 or 131 rpm at 60 Hz
74 or 109 rpm at 50 Hz
A
NOTE A: Depends on gear reducer used
