Nordson DuraBlue D4L Customer Product Manual

Parts
7-9
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
NoteQuantityDescriptionPartItem
— 1031232 Service kit, pump O-rings —
3 - - - - - -
S O-ring, -118, Viton, 0.862 x 0.103 in.
1
4 - - - - - -
S O-ring, Viton, 0.750 x 0.938 x 0.094 in.
1
5 - - - - - -
S O-ring, Viton, 1.188 x 1.388 x 0.094 in.
1
NS - - - - - -
S Grease, high-temperature, 0.50 oz
1
— 1037756 Service kit, seal, pump, 4.9 cc/rev —
NS - - - - - -
S Shaft, pump, 4.9 cc
1
NS - - - - - -
S Retaining ring, external, 75
2
NS - - - - - -
S Pin, dowel, 0.185 x 1 x 0.250
1
NS - - - - - -
S Seal, spring,
1
/
8
x 1 x 0.250
3
NS - - - - - -
S Washer, 0.989 x 0.789 x 0.040
1
NS - - - - - -
S Retaining ring, internal, 100, inverted
1
NS - - - - - -
S O-ring, Viton, 2
11
/
16
x 2
7
/
8
x
3
/
32
1
NS - - - - - -
S O-ring, Viton, 0.750 x 0.938 x 0.094
1
NS - - - - - -
S O-ring, –188, Viton, 0.862 x 0.103
1
NS - - - - - -
S O-ring, Viton, 1.188 x 1.388 x 0.094
1
NS - - - - - -
S Grease, high-temperature, 0.50 oz.
1
NS - - - - - -
S Key, machine drive, 0.125 x 0.75
1
NS - - - - - -
S Tool, seal insertion
1
— 1037757 Service kit, seal, pump, 7.8 cc/rev —
NS - - - - - -
S Shaft, pump, 7.8 cc
1
NS - - - - - -
S Retaining ring, external, 75
2
NS - - - - - -
S Pin, dowel, 0.185/0.184 dia. x 0.438 long
1
NS - - - - - -
S Seal, spring,
1
/
8
x 1 x 0.250
3
NS - - - - - -
S Washer, 0.989 x 0.789 x 0.040
1
NS - - - - - -
S Retaining ring, internal, 100, inverted
1
NS - - - - - -
S O-ring, Viton, 2
11
/
16
x 2
7
/
8
x
3
/
32
1
NS - - - - - -
S O-ring, Viton, 0.750 x 0.938 x 0.094
1
NS - - - - - -
S O-ring, –188, Viton, 0.862 x 0.103
1
NS - - - - - -
S O-ring, Viton, 1.188 x 1.388 x 0.094
1
NS - - - - - -
S Grease, high-temperature, 0.50 oz.
1
NS - - - - - -
S Key, machine drive, 0.1875 x 0.70
1
NS - - - - - -
S Tool, seal insertion
1
NOTE A: See Drive Assembly (Complete)
NS: Not Shown
