Nordyne P5RD Series User Manual

13
L
W
Top View
FIGURES AND TABLES
18.01
Electric Heater Power Supply
Power Supply
Low Voltage Supply
Control
Access
Panel
Blower Access Panel
H
17.86
15.36
10.10
3/4" NPT
Drain Connection
1"
12.13
1.38
3.2
3.2 5.29
9.15
9.04
17.50
14" diameter
Return Duct
Opening
12" diameter
Supply Duct
Opening
3.0
5.5
1"
3.15
A
B
Back (Duct) View
Side View
Model No.
GP5RD-
Length
-L-
Width
W
Height
-H-
-A- -B-
Return Diameter
(in)
Supply Diameter
(in)
024K 49 35 30.2 35.02 2.48
14 12
030K 49 35 30.2 35.02 2.48
14 12
036K 49 35 30.2 35.02 2.48
14 12
042K 49 35 30.2 35.02 2.48
14 12
048K 49 35 30.2 35.02 2.48
14 12
060K 49 35 34.2 35.02 2.48
14 12
Table 5. P5RD Physical Data
Figure 10. Unit Dimensions
