Chapter 3 Hardware Troubleshooting 35
BCM50 Troubleshooting Guide
Table 10 Level 1 reset
Step User action Power LED Status LED System state Alternative user action
1 Boot the system
Solid yellow Solid yellow Power self-test
No action; system
remains off
Solid yellow Off Power self-test
Flashing yellow Solid yellow Ready for reset input
2
Press reset switch Solid red Flashing yellow Request Level 1 reset
Do not press reset
switch; system boots
normally
3
Wait five seconds Flashing red Flashing yellow
Awaiting Level 1 reset
confirmation
Press reset switch;
system proceeds to
Level 2 reset
4
Press reset switch
Solid red Solid yellow
System performs
Level 1 reset
All configuration
programming erased.
Do not press reset
switch; system boots
normally
Solid green Solid green
System rebooted and
is ready for user
action.
Table 11 Level 2 reset
Step User action Power LED Status LED System state Alternative user action
1 Boot up the system
Solid yellow Solid yellow Power self-test
No action; system
remains off
Solid yellow Off Power self-test
Flashing yellow Solid yellow Ready for reset input
2
Press reset switch Solid red Flashing yellow Request Level 1 reset
Do not press reset
switch; system boots
normally
3
Press reset switch
again within five
seconds of the first
button press.
Solid red Flashing red Request Level 2 reset
Do not press reset
switch; system remains
in Level 1 reset state
4
Wait five seconds Flashing red Flashing red
Awaiting Level 2 reset
confirmation
Press reset switch;
system proceeds to
Nortel factory mode (do
not use)
5
Press reset switch
Solid red Solid red
System performs
Level 2 reset; all
configuration
programming and
software updates
erased.
Do not press reset
switch; system boots
normally
Solid green Solid green
System rebooted and
is ready for user
action.
