Appendices
105
Installation Position
Bearing Name
Model
Quantity
Bearings
Standard
Intermeidate section of the front
drive shaft
Single-row radial ball bearing
6006E
1
GB/T 276
Rear end of the small bevel gear shaft of
front drive
Tappered roller bearing
32207
1
Special
Front end of the small bevel gear shaft of
front drive
Tappered roller bearing
802048
1
Special
Differential of front drive
Tappered roller bearing
2007112E
2
GB/T 297
Intermediate section of the front
drive shaft
Single-row radial ball bearing
6007
2
GB/T 297
Bearing for the front wheel hub
Tappered roller bearing
819310
4
Special
Planetary gear shaft of the front
final drive
Rolling needle
5×23.8
GB/T 309
Inner flank of the steering knuckle
Tappered roller bearing
32209
2
GB/T 297
Outer flank of the steering knuckle
Tappered roller bearing
32307
2
GB/T 297
Kingpin of the steering knuckle
Thrust ball bearing with
flat seat
51210
2
GB/T 301
Bearing block for the auxiliary
clutch shaft
Angular contact ball bearing
7016AC
1
GB/T 292
Bearing block for the release shaft of
main clutch
Angular contact ball bearing
996712
1
Hand tailor
Bearing block for the sleeve of
steering column
Single-row radial ball bearing
6004
1
GB/T 276
At the bore of driving gear for the third
shift of gear box
Rolling needle bearing
KK64×74×41
1
JB/T7918
At the bore of driven gear of the first shift
of gear box
Rolling needle bearing
KK64×74×41
1
JB/T7918
At the bore of driven gear of the second
shift of gear box
Rolling needle bearing
KK64×74×41
1
JB/T7918
At the bore of auxiliary driven gear at the
rear end of gear box
Rolling needle bearing
KK55×65×43
1
JB/T7918
Front end of the power output
driven shaft
Bearing
6210
1
GB/T276
Rear end of the power output driven shaft
Tappered roller bearing
7212E
2
GB/T297
