Accessories and Consumables
3. Accessories and Consumables
3.1 Accessories
Tractor accessories include the heater, interior decoration, floor mats, AC, swing traction rod, etc.
3.1.1 Heater
The tractor cab heater is in the top front of the cab. There is a heater
switch on the heater that turns the heater fan on and off, in order to
ensure a comfortable working temperature in the cab. The engine
coolant supply valve must be turned on to use the heater.
When ventilation is needed in the cab, especially in the summer,
unheated air can be supplied by turning off the engine coolant
supply valve and turning on the fan. Figure 3-1 Heater
The heater and the air conditioner both use four circular vents just inside the front window of the cab, and two
vents above the driver’s head. All the vents are located in the cab headliner.
3.1.2 Floor Mats
The floor mats consists of four pieces made of 10 mm. soft rubber. The mats are fixed on the floor with
plastic buckles. When removing, the floor mat can be taken up only after the button/snaps are pried up slightly
with a screwdriver. To put them back, place them in the original position and reapply the buckles.
3.1.3 Fender Gaskets
With applied PVC foam surface adsorption material and molding, the whole fender gaskets are fixed on to the
right and left fender by plastic buckles.
3.1.4 Swing Traction Rod
The swing traction rod is used for traction type farm implements.
The traction rod is connected to the farm implement with a traction pin.
The traction rod can swing both ways, which makes mounting farm
implements more convenient. However, when the tractor is towing a
farm implement backward, the positioning pin (1) must be inserted into
the hole of the traction plate, in order to stabilize the traction rod
(2) The traction point can be adjusted to the right height by turning
the traction rod, in order to connect the farm implement.
Figure 3-2 Swing Traction Rod
1. Positioning Pin 2. Traction
Rod
