Nortrac 82XTC - Technical Specifications; Four Wheel Drive Tractor Technical Specifications

Technical Specifications
93
7. Technical Specifications
7.1 Four Wheel Drive Tractor Technical Specifications
Table 7-1 Technical Specifications for NorTrac 82XTC Tractor
Item
Unit
Technical Parameters
TD824/TD904
Type
——
Wheeled 4x4
Nominal traction power
kN
19/21.3
Maximum power of the PTO shaft
kW
54.3/59.4
Outside size
Length (incl. rear suspension)
mm
4530(incl. front counterweight)
Width (outside tire)
mm
2050
Height (up to the top of muffler)
mm
2810
Wheelbase
mm
2195/2366
Tread
Front wheel
mm
1610.1950(out of the factory 1610/1680)
Rear wheel
mm
1620.2020(out of the factory 1620)
Ground clearance
Min. ground clearance
mm
405(down side of front drive axle)
Agricultural interval
mm
420
Turning circle
radius
When the single sided brake is used
m
4.2±0.3
When the single sided brake
is not used
m
4.9±0.3
Structural mass
Model with cab
kg
3850
Model without cab
3600
Least used mass
Model with cab
kg
4200
Model without cab
3900
Mass distribution
Front shaft
With the cab
kg
1690
Without the cab
1560
Rear shaft
With the cab
2510
Without the cab
2340
Counterweight
Front counterweight (option)
kg
242 or 310 or 440
Rear counterweight (option)
kg
320 or 480
Transmission
system
Clutch
——
Single plate, dry type, double action clutch
Gearbox
——
Combined 4x(2+1),8 drive gears. 4 reverse
gears.clamping gear for option, or shuttle
shifting: 4x(2+1)x2; 16 drive gears.8 reverse
gears.master and auxiliary gear shifting,
spur gear meshing bushing shifting
Rear axle
Central transmission
——
Spiral bevel gear
Differential
——
4 planet bevel gears
Differential lock
——
Spline bushing
