Nortrac 82XTC - Hydraulic Suspension, PTO, and Electrical System Operation

Operation Instruction
32
2.15 Driver’s Seat Adjustment
2.15.1 Forward and Backward Driver’s Seat Adjustment
There is a lever underneath the driver’s seat, on the right side. While sitting
on the seat, pivot the lever outwards to the right and use your weight to
slide the seat forwards or backwards until it is in a comfortable location.
Then release the lever and the seat will lock in place.
2.15.2 Driver’s Seat Firmness Adjustment
The driver’s seat hand wheel (1) adjusts the seat firmness according
to the height and weight of the driver.
Figure 2-34 Driver’s Seat Firmness Adjustment
NOTES:
1. For safety, the seat should not be adjusted unless tractor is stopped and in park, to avoid an accident.
2. Making the seat too soft can make running the tractor on uneven surfaces particularly challenging and
can cause a loss of sight lines.
2.16 Hydraulic Suspension, PTO, and Electrical System Operation
The Series 82XTC tractor uses a semi-separate hydraulic lifting system (3-point hitch) with two types of
adjustment modes: position adjustment and height adjustment. The control handle of the control distributor valve
is used to raise and lower farm implements. Push the handle forward to lower an implement; and pull it back to
raise an implement. See ―Hydraulic Lifting System Adjustment‖ for the adjustments to reach the maximum
raising position and the minimum lowering position.
A power output device (PTO) is used to deliver power to farm machinery. A swing traction device is used with a
harrow or a lawn mower.
Figure 2-33 Forward/Backward
Driver’s Seat Adjustment 1 bolt
