Appendices
107
Installation Position
Specification
Standard
Quantity
Lifter cylinder body
118×3.55G
GB/T3452.1
1
Piston of the brake
260×3.55G
FT800.43.149
2
Piston of the brake
300×3.55G
FT800.43.150
2
Power output operating-
handle shaft
17×1.8G
GB/T3452.1
1
Protective sleeve for the front
drive axle
45×3.55G
GB/T3452.1
4
Operating shaft of the transfer case
17×1.8G
GB/T3452.1
2
Front drive axle bevel pinion shaft
31.5×1.8G
GB/T3452.1
1
Bearing block for the front drive
semi-axle
80×2.62G
4966231
2
Rear base for the front drive axle
99.6×5.3G
GB/T3452.1
2
Front base for the front drive axle
52.6×3.55G
GB/T3452.1
1
Oil inlet joint of the distributor
12.5×2.65G
GB/T3452.1
1
Manual brake camshaft
15×2.65G
GB/T3452.1
2
Steering shaft
15×2.65G
GB/T3452.1
1
Elbow joint at the oil pump outlet
20×2.65G
GB/T3452.1
1
Fork shaft of the differential lock
20×2.65G
GB/T3452.1
1
Connecting plate at the oil
pump inlet
21.2×2.65G
GB/T3452.1
1
Fork shaft base of the
differential lock
30×2.65G
GB/T3452.1
1
Swing pin of the front axle
50×5.3G
GB/T3452.1
2
Elbow joint at the oil pump outlet
15×2.65G
GB/T3452.1
1
Connecting plate at the oil
pump inlet
21.2×1.8G
GB/T3452.1
1
Where the oil suction pipe joint
meets the lifter housing
26.5×2.65G
GB/T3452.1
1
Where the oil suction pipe joint
meets the oil suction filter
32.5×2.65G
GB/T3452.1
1
