18 AFP-200 Instruction PN 15511:F2 10/11/99
1.8 Specifications
Primary AC Power
• For the AFP-200: 120 VAC, 50/60 Hz, 3.0 A.
• For the AFP-200E: 220/240 VAC, 50/60 Hz, 1.5 A.
• Wire size: minimum 14 AWG with 600 VAC insulation.
Battery (lead-acid only)
• Maximum Charging Circuit – Dual Rate High Charge is 29.1 V @ 0.7 A; Normal Flat Charge is 27.6 V @
0.5 A.
• Maximum Battery Capacity – 17 AH. (Batteries larger than 12 AH require a BB-17 or other UL-listed
battery cabinet.)
Communication (SLC) Loop
• 24 VDC nominal, 27.6 VDC max.
• Maximum length is 10,000 ft. per channel (NFPA Style 4) or 10,000 ft. total twisted-pair length (NFPA Style
6 and 7).
• Maximum loop current is 250 mA (max short circuit) or 100 mA (normal).
• Maximum loop resistance is 40 ohms.
• Supervised and power-limited.
Notification Appliance and Releasing Circuits
• Power-limited circuitry.
• Max. wiring voltage drop: 2 VDC.
• Normal Operating Voltage: 24 VDC.
• NAC circuit 1 = 2.5 A
• NAC circuits 2-4 = 2.5 A shared total
• Current for all external devices: 5.0 A.
• Optional AVPS-24/AVPS-24E: additional 3.0 A of notification appliance power (see Appendix J).
• Max. signaling current/circuit: 2.5 A.
• End-of-line resistor: 4.7K, 1/2-Watt (PN 71252 UL-listed) for Notification Appliance Circuits.
• REL-4.7K for releasing circuits (REL-47K for use with CMX).
Alarm, Trouble, and Supervisory Relays
Power-limited circuits only. Contact ratings:
• 2.0 A @ 30 VDC (resistive), 0.5 A @ 30 VAC (resistive).
• Alarm and Trouble: Form-C.
• Supervisory: Form-A.
Four-wire Smoke Detector Power (24 VDC ± 5%) TB1 terminals 5 and 6
• Max. ripple voltage: 10 mVrms.
• Up to 500 mA is available for powering four-wire smoke detectors
1,2.
Non-resettable Regulated 24 V Power (24 VDC ± 5%) TB1 terminals 3 and 4
• Max. ripple voltage: 10 mVrms.
• Total DC current available from this output is up to 500 mA (subtracted from four-wire smoke power)
2
.
High Ripple Regulated 24 V Power (24 VDC ±10%) TB1 terminals 1 and 2
• Max. ripple voltage: 2 V
RMS
• Total DC current available for powering external devices is 1.0 A standby and 1.5 A alarm
2
.
• This power is not recommended for LCD-80 or ACS annunciators except for ACM-8R.
1
For power supply calculations, refer to Appendix A.
2
Total current for regulated power, non-resettable power, four-wire smoke power, and four Notification Appli-
ance Circuits must not exceed 5 A or 8 A if using an AVPS-24 (refer to Appendix J). Total external system
current in excess of 2.5 A requires 12 AH or 17 AH batteries—not 7 AH.
