Point Status
A typical Read Status display example for a point
read is shown to the right.
• NORMAL is the present status. Status can be
ALARM, TROUBL, DISABL, etc.
• SMOKE(PHOTO) is the device type. Device
types include SMOKE [ION], PULL STATION,
HORN CIRCUIT, etc.
• WEST HALLWAY FLR 5 is the custom label programmed for this device.
• Z05 Z01 Z15 Z87 Z90 is a list of assigned software zones (if less than five are programmed, some are blank).
• 15% is the current reading of percent of alarm, 15% of 1.0% would be 0.15% obscuration per foot (does not
exist for modules).
•1.0% is the alarm threshold selection (does not exist for modules).
•D indicates drift compensation is enabled.
•P indicates Pre-Alarm is enabled.
•V indicates that the detector is programmed for Alarm Verification. The 08 is a verification tally and indicates
that this device entered the verification cycle eight times since the counter last cleared. Note: The verification
field does not exist if this device is a module. If the device is a control module or Notification Appliance
Circuit, an “S” or “W” may appear in this area, indicating that the module is programmed for Silenceable or
Walk Test activation.
•D indicates that this device is a detector and the detector address is 13. Note: M is for a module, B is for a
Notification Appliance Circuit, and Z is for a software Zone.
If the point is not installed, a Read Status command to that point will result in a NOT INSTALLED message on
the display.
Software Zones 01-89
The typical display shown to the right is used to show
the status of Zones 01-89.
• OFF is the zone status (status can be ON or OFF)
• FLR 5 MAIN BUILDING is the custom label pro-
grammed for this zone.
• Z20 is the zone number.
Note: To read the status of a zone directly, press *,
press * again, then enter the zone two digit number
and Enter. To read the system parameters, press *, * , Enter.
Software Zone 90
The typical display shown to the right shows the
status of software zone 90 (Pre-signal Delay control).
• DELAY=180 indicates the programmed pre-sig-
nal delay in seconds.
• PAS=YES (could be NO) indicates that Positive
Alarm Sequence operation is selected in the pro-
gram.
NORMAL@SMOKE(PHOTO)
WEST@HALLWAY@FLR@5
Z05@ZO1@Z15@Z87@Z90
15%@1.0%@DPV08@D13
OFF@SOFTWARE@ZONE
FLR@5@MAIN@BUILDING
@@@@@@@Z20
OFF@SOFTWARE@ZONE
PRESIGNAL@DELAY
DELAY=180
PAS=YES @@@@@@@Z90
