Notifier FCPS-24S8 User Manual

DIP Switch Settings Programming Options
FCPS-24S PN 51977:C1 08/06/03 19
3.1 DIP Switch Settings
The following table lists the FCPS programmable features and the switch settings
required to select a particular feature. A detailed description of each feature is
presented in the following pages.
Table 3.1 DIP Switch Settings
SW1 DIP Switch ON OFF
1
This switch works in conjunction with switch 2 to determine the Strobe Synchronization Type
1
.
2 1 OFF, 2 OFF = no sync (steady +24V)
1 OFF, 2 ON = System Sensor
1 ON, 2 OFF = Gentex
1 ON, 2 ON = Wheelock
3 FCPS configured for Slave Synchronization FCPS configured for Master Synchronization
4 Delay AC Fail Reporting for 8 Hours No Delay in AC Fail Reporting
5 This switch works in conjunction with switch 6 to determine Input to Output functions
6 5 OFF, 6 OFF = General Alarm
• FCPS configured as Master (switch 3 OFF), NAC Outputs 1 through 4
2
are controlled by Control
Input #1; Sync Input is ignored.
• FCPS configured as Slave (switch 3 ON), NAC Outputs 1 through 4
2
are controlled by Control
Input #1; Sync Input is monitored
3
.
• Resettable or nonresettable Auxiliary Power Output is available from TB4 Terminals 9 & 10. Control
Input #2 determines if reset will occur (must go from On to Off for a 6 second reset to occur).
• Output #4 function follows DIP switch 8 setting.
5 OFF, 6 ON = Split Alarm
• FCPS configured as Master (switch 3 OFF), NAC Outputs 1 & 2 are controlled by Control Input #1
and Outputs 3 & 4
2
are controlled by Control Input #2; Sync Input is ignored.
• FCPS configured as Slave
5
(switch 3 ON), NAC Outputs 1 & 2 are controlled by Control Input #1
and Outputs 3 & 4
2
are controlled by Control Input #2; Sync Input is monitored
3
.
• Only nonresettable Auxiliary Power is available from TB4 Terminals 9 & 10.
• Output #4 function follows DIP switch 8 setting.
5 ON, 6 OFF = Split Temporal
• FCPS configured as Master (switch 3 OFF), Control Input #1 controls NAC Outputs 1 & 2
and Control Input #2 controls Outputs 3 & 4
2
which will generate a Temporal code signal without
sync; Sync Input is ignored.
• FCPS configured as Slave (switch 3 ON), Control Input #1 controls NAC Outputs 1 & 2 and Control
Input #2 controls Outputs 3 & 4
2
which will generate a Temporal code signal without sync; Sync
Input is monitored for Outputs 1 & 2
3
.
• Only nonresettable Auxiliary Power is available from TB4 Terminals 9 & 10.
• Output #4 function follows DIP switch 8 setting.
5 ON, 6 ON = Selective Silence
• FCPS configured as Master (switch 3 OFF), NAC Outputs 1 through 4
2
are controlled by Control
Input #1; Sync Input is ignored.
• FCPS configured as Slave (switch 3 ON), NAC Outputs 1 through 4
2
are controlled by Control
Input #1; Sync Input is monitored
3
.
• Control Input #2 determines when Selective Silence for all outputs will occur
4
• Only nonresettable Auxiliary Power is available from TB4 Terminals 9 & 10.
• Output #4 function follows DIP switch 8 setting.
7 Disable Charger Enable Charger
8 Output Circuit #4 = Door Holder Output Circuit #4 = NAC
1
Strobe Synchronization only works with non-coded NACs.
2
If Door Closer function is selected (switch 8 ON), Output 4 does not function as an NAC, therefore sync input is ignored for it.
3
If no synchronization is selected by switches 1 & 2, the Sync Input is ignored.
4
Selective Silence allows the silencing of the sounder portion of a horn/strobe combination device without turning off the strobe.
5
When using Split Alarm with power supply configured for Slave Mode, System Sensor can not be used (use System Sensor with Master Mode
only).
