General Information Operating Features
10 NFS-3030 Operating P/N 51344:C 11/4/03
System Reset, and Drill Fixed Function keys, or the SIGNAL SILENCE, SYSTEM RESET, and
ACKNOWLEDGE soft keys. These functions must be performed by a remote device preprogrammed
for this purpose. When this panel is not the DCC on a network, permission must be granted from
the DCC before Signal Silence, System Reset, Acknowledge or Drill can be performed at this
panel. Pressing one of these keys will automatically send a permission request to the DCC.
Keypad
The alphanumeric portion of the keypad is in standard QWERTY format. This keypad is functional
mainly when an entry is requested by the system. Otherwise, pressing the keys results in no entry.
Soft Keys
The ten keys to the right and left of the display function to select commands that appear on the
display. Each screen has different information, and each key changes function to suit the screen.
Beneath each screen in this manual is a description of the function of each soft key.
Fixed Function Keys
The eight keys aligned along the upper right edge of the keypad/display are fixed function keys.
FIRE ALARM
SCROLL/DISPLAY
SECURITY SCROLL/DISPLAY
SUPERVISORY
SCROLL/DISPLAY
TROUBLE
SCROLL/DISPLAY
OTHER EVENT SCROLL/DISPLAY
SIGNAL SILENCE - Press this key to turn off all control modules and panel output circuits that
have been programmed as silenceable. Signal Silence is disabled while the Silence Inhibit Timer is
in effect, or when a device with a Waterflow type code initiates a fire alarm.
DRILL
HOLD 2 SEC. - Press this key, holding it down for 2 seconds, to activate all silenceable fire
output circuits.
SYSTEM RESET - Press this key to clear all latched alarms and other events as well as turn off
event LEDs. If alarms or other off-normal events exist after reset, they will resound the system and
relight the LEDs. Unacknowledged events will not prevent reset from functioning unless the panel
is programmed for Receive Mode (refer to the note on page 21). The SYSTEM RESET key will not
function if the programmable Silence Inhibit Timer is running.
The System Reset key will not immediately silence active outputs. If the Control-by-event programming
conditions for the output are not met after reset, the output will deactivate. (Typically 30 seconds local,
60 seconds network.)
Special Function Keys
To the right of the QWERTY keypad are special function keys.
Arrow Keys - Pressing these keys navigates through the programming fields on a display screen by
advancing or reversing the cursor position.
Enter - Pressing this key navigates through the programming fields on a display screen by
advancing the cursor.
Esc - Press this key once to leave the current field without saving the entry. Press this key twice in
succession to discard any changes made on the screen and exit to the previous screen.
DISABLE/ENABLE - For future use. No function at this time.
PRINT SCREEN - Press this key to print what is displayed on the display screen.
LAMP TEST - Press this key to test the LED indicators on the left of the keypad, the panel circuit
LEDs, and the piezo. Pressing the key longer than 5 seconds will display firmware version numbers
on the display screen.
F1 - For future use. No function at this time.
NEXT SELECTION/PREVIOUS SELECTION - Use these keys to scroll through the list of
possibilities in a data field on the display screen.
Scroll through a list of events of these types,
each of which will appear on the display once
the associated button is pushed. The OTHER
EVENT
SCROLL/DISPLAY key also scrolls
between prealarm and disabled events.
