Read Status Control Module
42 NFS-3030 Operating P/N 51344:C 11/4/03
Display
Lines 1 through 10 - Refer to the descriptions in "Smoke Detector" on page 39 with the exception
of line 6, which is described below.
Line 6 - This line displays statistics that display for control module output points; in the above
example they are:
AUTOMATIC OFF
The first field displays the point control. There are four designations that could appear in this field
The second field displays the point status. There are two designations that could appear in this field.
The device is a control module (an output device) so by referring to the descriptions below, it can
be determined that the point is in a normal state.
Outputs: (Control Modules)
If the point is not in trouble or disabled and the status is Automatic, the display will read:
AUTOMATIC OFF
AUTOMATIC ON
AUTOMATIC OFF-HOOK
If the point has been forced into a manual control state, the display will read as follows. <Trouble
Status> will appear when there is a point trouble.
MANUAL OFF <Trouble Status>*
MANUAL ON <Trouble Status>*
MANUAL OFF-HOOK <Trouble Status>*
If the point is disabled, the display will read as follows. <Trouble Status> will appear when there is
a point trouble.
DISABLED OFF <Trouble Status>*
DISABLED ON <Trouble Status>*
DISABLED OFF-HOOK <Trouble Status>*
If the point is in trouble, the display will read:
TROUBLE OFF <Trouble Status>*
TROUBLE ON <Trouble Status>*
TROUBLE OFF-HOOK <Trouble Status>*
*The field <Trouble Status> will contain one of the device trouble messages listed in Table 2.1.
Line 11 - blank.
Line 12 - WALK TEST - Displays YES if the device sounds during audible Walk Test.
Line 13 - SILENCEABLE - Displays YES if the operator can manually silence an activated output.
The output resounds for fire.
Line 14 - SWITCH INHIBIT: YES - Displays YES if the operator can not manually activate an output.
Line 15 - The current time and date are displayed in this line.
Line 16 - Press
BACK to return to the previous screen.
Point Control
Designation
Description
AUTOMATIC The point is being controlled automatically by the panel.
MANUAL The point has been forced into manual control state by an outside source.
DISABLED
A status change other than a change to MANUAL control has caused the
point to go off automatic control.
TROUBLE
Point Status
Designation
Description
OFF The point is currently not activated.
ON The point is currently activated.
OFF-HOOK The telephone point is currently off-hook.
