− Snap to Canvas: Same as the width and height of the canvas
− Fill Screen: Same as the width and height of the screen

Width: Set the layer width.

Height: Set the layer height.

H Position: Set the horizontal coordinate (X) of the layer on the canvas.

V Position: Set the vertical coordinate (Y) of the layer on the canvas.

Priority: Set the Z coordinate of the layer on the canvas. The greater the value, the higher priority.

Crop: Turn on or off input crop and set the crop size and position.

Border: Turn on or off layer border and set the border thickness and color.
If necessary, select other layers and set the related parameters.
