VX16s All-in-One Controller
User Manual
www.novastar.tech
4

Support for resolution of 1920×1080@60Hz
Control
Connector
Qty
Description
ETHERNET
1

Connect to the control PC for communication.

Connect to the network.
USB
2

USB 2.0 (Type-B):
- Connect to the PC for debugging.
- Input connector to link another device

USB 2.0 (Type-A):

Output connector to link another device
RS232
1
Connect to the central control device.
Note:
The HDMI source and DVI Mosaic source can be used by the main layer only.
