VX6s All-in-One Controller
User Manual
5 Specifications
29
DVI
2
VESA standard
Supports input resolutions up to
1920×1200@60Hz and downward compatibility.
Supports HDCP.
DVI LOOP
1
DVI loop output connector
HDMI
2
Supports input resolutions up to
1920×1200@60Hz and downward compatibility.
Supports HDCP.
Output
Connector
Quantity
Description
Ethernet
6
6 Ethernet outputs
DVI
1
A monitoring connector, which can be set to
preview the editing image or monitor the PGM
Control
Connector
Quantity
Description
ETHERNET
1
Connects to the PC for communication, or to the
network.
USB (Type-B)
1
On the front panel, type-B

Connects to the PC for device control.

Used as the input port for cascading devices
U-DISK
1
On the front panel, type-A
Reserved connector
USB (Type-B)
1
On the rear panel, type-B

Connects to the PC for device control.

Used as the input port for cascading devices
USB (Type-A)
1
On the rear panel, type-A
Used as the output port for cascading devices
Overall Specifications
Connector
Quantity
Description
Power
connector
1
AC100-240V~50/60Hz
Power consumption
65 W
Operating temperature
-20°C–60°C
Dimensions
1U standard chassis
Weight
2.71 kg
