Also, note the black insertion indication, which should be adjacent to the inlet’s edge.
Connecting the Handpiece to the Console [The Handpiece Connector in the image may differ from the one that you have]
Make sure the I/O button of the console is switched off.
Connect the power cable to the power inlet (marked in yellow) on the Console’s back panel and to a
suitable power source (according to the system’s electrical safety guidelines and technical specifications).
Power Inlet on the Console's Back Panel
Never disconnect a Handpiece under load. It must be connected/disconnected only
after the system has been shut down. Neglecting to do so may result in system damage.
