Nox A1 Manual
~ 17 ~
Attaching the Nox A1 and the Nox RIP Belts
 Caution: The Nox A1 recorder and Nox disposable RIP belts should be worn over
clothing to prevent allergic reaction to the equipment materials.
 Warning: The Nox disposable RIP belts are single use and single patient use. Re-
using the disposable RIP belts may affect the quality of recorded signals and lead
to possible incorrect treatment. Using the same disposable RIP belt on more than
one patient poses a risk of cross-infection.
Step 1
Snap the clips that are attached to the Nox A1 recorder to the patient’s shirt.
1
Step 2 to Step 4
• Snap the Nox abdomen cable to the back of the device.
• Place a Nox disposable RIP belt around the thorax and snap its ends to the back panel of the
device.
• Adjust the Nox abdomen cable length as needed by wrapping it around the abdomen
connection unit. Place a Nox disposable RIP belt around the abdomen and snap it in place.
2
3
4
