Nox A1 Manual
~ 37 ~
Specifications
Nox A1 and Accessories
DESCRIPTION
PROPERTIES
FUNCTION
Nox A1 Storage Capacity
 1GByte
Nox A1 Recording Time
 8 hours
Nox A1 Internal Channels
 Two RIP Respiratory Effort
 Pressure
 Respiratory sound/snoring
 Four bipolar
 Thirteen unipolar
 Position
 Activity
 Light
Nox A1 External Channels
 Oximeter data via Bluetooth®
 Capnography data via Bluetooth®
 CPAP data via Bluetooth®
PHYSICAL
Nox A1 Dimensions
 82 mm (3.2”) W, 63 mm (2.5”) H, 21 mm (0.85”) D
Nox A1 Weight
 132 g (163 g with battery) (0.29 lbs (0.36 lbs with battery))
Nox A1 Bipolar Inputs
 Touch proof 1 mm keyhole connector
 Input range ±1024 mV DC
 Bandwidth 0.1 - 85 Hz
 Input impedance >5 MΩ
 Sampling Rate = 256 kHz
 Storage rate = 200 Hz
Nox A1 Unipolar Inputs
 Touch proof DIN 42-802
 Input range ±3.2 mV AC
 Bandwidth 0.1 - 85 Hz
 Input impedance >5 MΩ
 Sampling Rate = 256 kHz
