NSD VARICAM VS-5F-1 User Manual

39
INTRODUCTORY 6. WIRING and CONNECTION
6-3-6. Communication Connector Pin Arrangement
Uses the serial communication connector when connecting the PLC, computer, or peripheral device.
◎Serial connector (SERIAL)
[ Connector: D-Sub 9-pin ]
Pin No.
Signal name
Description
Notes
1
DATA-
－
2
RXD
Receive Data
3
TXD
Send Data
4
DTR
Data Terminal Ready
5
SG
Signal Ground
6
DSR
Data Set Ready
7
RTS
Request To Send
8
CTS
Clear To Send
9
DATA+
－
Mounting
screw
SHIELD Cable shield Shield must be connected.
Connector on the VARICAM side
Model : DELC-J9PAF-13L6E (9-pin male)
Manufacturer : Japan Aviation Electronics Industry, Ltd.
For more details about the serial communication, please contact your NSD representative.
