8
FX22 (Fig. 3, 4)
1) Turn the Latch Plate to open the chuck.
2) Insert the bur into the chuck until the bur securely
engages. Swing the Latch Plate back to closed position.
3) Ensure that the bur is secure by gently pulling and pushing
the bur.
5-2 Removing the Bur/File
FX15 / FX15m / FX23 / FX23m / FX25 / FX25m / FX75 / FX75m (Fig. 5)
Depress the Push Button to open the chuck ( ) and remove
the bur/file ( ).
FX22 (Fig. 3)
Turn the Latch Plate to open position and pull the bur out.
CAUTION
• Do not use burs/files with problems listed below as the
bur/file may break, seize up or disengage from the chuck.
- Bent, deformed, worn, rusted, broken, deficient bur/file.
- Bur/File which is cracked on the edge or axis.
- Non-ISO(EN ISO) standard, or tampered bur/file.
• Do not use burs/files other than specified in
"11. Specifications" as such burs/files may be
accidentally released or break d
uring rotation.
