22
NOTICE
15. Protection Circuit
It may overheat inside when you use this Control Unit in
more than Power 8 at G mode for long time.
In this case, Protection Circuit reduces the Power
automatically. (Power 7)
Bar Graph Indicator from 8 to 10 flashes. (Fig.45)
After Protection Circuit is released, the flashes stop.
However, Power Level can not automatically increase. If
needed, increase manually.
• During Protection Circuit function (during Bar Graph Indicator flash), the Control Unit can not increase the Power
Level.
• If Power Level decreases less than 7, Bar Graph Indicator stops flashing. However, it the Power increase more
than 8, flashes it again.
14. Specifications
Type NE255
Power Source
AC120V 50/60Hz
AC230V 50/60Hz
Vibration Frequency 28-32kHz
Maximum Output 11W
Rated Power 29VA
Water Pressure 0.1-0.5MPa (1-5kgf/cm
2
)
Lighting
Varios 970 : No
Varios 970 LUX : Yes
Bottle Volume 400mL (Per Bottle)
Dimensions W160 x D270 x H190mm (Including Bottle)
Weight 2.1kg (Except attachment)
Use Environment
Temperature 0 - 40 ˚C (The liquid must not freeze up)
Humidity 30 - 75 %
Atmospheric pressure 700 - 1060 hPa
Store Environment
Temperature -10 - 60 ˚C
Humidity 10 - 85 %
Atmospheric pressure 500 - 1060 hPa
Fig.45
