2. Component Names
Optic Non-OpticNon-OpticOptic
No. Parts Name Quantity
1 Control Unit 1
2 VA Bottle 2
3 AC Power Cord 1
4 Varios2 Handpiece (Optic or Non-Optic) 1
5
Handpiece Cord (Unshielded 2M)
(Optic or Non-Optic)
1
6 Foot Control 1
7 Sterilization Case 1
8 Tip Wrench 3
9 Tip G4 1
10 Tip G8 1
11 Tip G16 1
12 O-Ring (Thin section) (For VA Bottle) 2
13 O-Ring (Thick section) (For VA Bottle) 2
14 O-Ring (For Handpiece Cord) 2
15 Water Connector (Option) 1
16 Water Tube (Option) 1
17 Spanner Wrench (5x8) (Option) 2
18 Tip Cover S (Option) 1
19 Tip-Power Guide 1*
20 Tip Card 1*
21 Operation Manual 1*
* Operation Principle
A sinusoidal electrical signal, at ultrasonic frequency ( f > 20Khz ), is delivered by the generator. This signal is applied
to the ‘piezoelectric ceramic’ located inside the transducer. Piezoelectric ceramic converts this signal into mechanical
vibrations. These vibrations are at the same ultrasonic frequency as the electrical signal. The mechanical vibrations
are propagated towards the distal end of the transducer. The “TIP” insert, which is attached at the distal end of the
transducer, vibrates at ultrasonic frequencies and makes it possible to achieve the aimed purpose.
* These are not on photo above.
Option
1
2
3
4
5
119 10
15
16
17
18
6
7
8
12 13 14
