5 - 58 en-938821/2
Actions
Press the "E/DISG" button on the machine panel.
Immediate interruption of machining and retraction in accordance with the procedure defined in the part programme.
The "CYHLD" indicator is displayed in the status window (See 3.1.3), the "INCYC" indicator remains displayed.
The axis recall indicator flashes in the status window (See 3.1.3).
In the current position pages, the "TO GO" column displays the distance from the stop point.
Perform the operations required.
Return the axes to their interrupted position (See 5.5.1.2).
Restart the machining procedure by pressing the "CYCLE" button.
The programme continues.
5.5.1.12 Intervention and Programme Resumption after an Error
During execution of a programme on the machine (see 5.4.3), the operator may decide to intervene if an error is
detected by the system with display of a listed error message (see Appendix B for the list of error messages).
Before intervening, the operator should check the type of error message, which may be:
- an error message related to programming
- a machine error message (see 5.5.1.13 for the special case of programme resumption after a following error).
Case of programming error and programme resumption
Requirements
Programme interrupted in single step, automatic or dryrun mode. The fault indicator is displayed in the status window
(see 3.1.3) and an error message is displayed in the dialogue window of the information, programme and current
position pages, e.g.:
error 872 Block N120
No dimensions in blank definition
Actions
For messages with more than one line, display the complete message by pressing:
☞
HELP
Analyse the message and the cause of the error.
Select Edit mode (see 5.5.2.1).
The error message is cleared and the start of the programme is displayed. The fault indicator is cleared.
REMARK In certain cases, it is necessary to acknowledge the error message by pressing:
.
Correct the programming error (see 5.4.2.2).
REMARK For security, it is recommended to test the programme (see 5.4.2.6) before
resuming machining.
When editing is finished, machining can be resumed:
- au début du programme (Voir 5.4.3) ou à un bloc déterminé dans le programme (Voir 5.5.1.5),
- dans les modes, séquentiel (SEQ), continu (CONT), ou rapide (RAP) (Voir 5.4.3.2).
