en-938821/2 5 - 63
CNC Operation
5
Code selection
The operator selects the character code (ISO or EIA) used to save programmes and tool dimensions.
Switch between codes. ☞
SHIFT
+
#
3
Display of the selected code at the bottom of the screen.
REMARK Only the ISO code can be used to print a programme or tool offsets.
5.6.1 Unloading Programmes
Unloading part programmes consists of transferring the characters comprising the programme to a computer or
peripheral to:
- Backup the programme on a storage medium,
- Print the programme listing.
Systems with axis multigroups
In systems with axis multigroups, a programme must be defined by a prefix (% [Programme No.]) followed by a dot
and then a suffix corresponding to the number of the axis group to which the programme is assigned.
Unloading a programme defined only by its prefix (e.g. %28) causes all the associated programmes for each axis group
(%28.1, %28.2, %28.3, etc.) to be unloaded one after the other (without Xoff characters in between).
5.6.1.1 Unloading the Active Programme
Requirements
Unloading from a peripheral Unloading from a computer
Link established with the peripheral Link established with the computer and
(See C.2) file name selected (See C.3)
Peripheral ready to receive data
(See peripheral manual)
"FILE UNLOADING" menu displayed on the screen and transmission line and character code selected (See 5.6).
Actions
Select "ACTIVE PROGRAMME". ☞
)
0
The cursor moves to the following line:
0 ACTIVE PROGRAMME
Start unloading. ☞
Display of the "INCYC" indicator in the status window (See 3.1.3).
The programme is unloaded to the peripheral for backup or printout.
Display of the programme being unloaded.
When the unloading procedure has been completed, the "INCYC" indicator disappears and the "FILE UNLOADING"
menu is displayed.
REMARK When several programmes with different suffixes (%X.0, %X.1, %X.2, ...)
correspond to the number of the active programme, these programmes are
archived one after the other (without Xoff characters between).
