en-938821/2 5 - 65
CNC Operation
5
Incidents
When the programme selected does not exist, the cursor moves to the "%".
Enter the name of another programme in the dialogue line and restart the
procedure.
Exit from the procedure
Stop the unloading procedure. ☞
The unload mode and "INCYC" indicators disappear and the current position page is displayed (See 4.2).
5.6.2 Unloading Tool Tables
Tool tables are unloaded by transferring the values comprising the table to a computer or peripheral in order to:
- save them on a storage medium.
- print them out.
Requirements
Unloading from a peripheral Unloading from a computer
Link established with the peripheral Link established with the computer and
(See C.2) file name selected (See C.3)
Peripheral ready to receive data
(See peripheral manual)
"FILE UNLOADING" menu displayed on the screen and transmission line and character code selected (See 5.6).
Actions
Select "TOOL OFFSETS". ☞
!
1
The cursor moves to the following line:
1 TOOL OFFSETS
Start unloading. ☞
Display of the "INCYC" indicator in the status window (See 3.1.3).
The tool offsets are unloaded to the peripheral for backup or printing.
When the unloading procedure has been completed, the "INCYC" indicator disappears.
Exit from the procedure
Stop the unloading procedure. ☞
The "INCYC" indicator disappears.
