CNC Operation
5
Loading Tool Offsets
This operation requires the presence of a formatted diskette in the drive. It loads the tool offsets saved in a diskette
file onto the CNC.
Select the directory containing the file to be loaded (See 5.9.5.3).
Select tool offset load. ☞
TRANSF.
Display in the dialogue window of:
Transfer >Filename: ❚
Enter the name of the file to be loaded (See syntax). ☞
Syntax
[filename].[ext]
[filename] name of the file containing the tool offsets to be loaded
[ext] extension of the file containing the tool offsets to be loaded.
Display of the message:
loading tool offsets:
[filename].[ext]
in progress...
When loading is complete, the dialogue line is cleared.
The tool offsets are stored.
End of the Procedure
Exit from the page. ☞
OUT
Exiting from the page does not interrupt loading in progress.
