en-938821/2 8 - 7
8
Operator-Accessible Maintenance
!
CAUTION
The battery must be replaced within 15 minutes at most so as not to lose the backed up
data present the PC (RAM CMOS). A capacitor takes over for the battery to supply the
DRAM memory modules during replacement.
8.1.2.2 Adding a DRAM Memory Module
Tilt the module into the connector with the fool-proofing notch on the left (1).
2
1
Notch
Push the module down into a horizontal position until it snaps into place (2).
