Connection to GNT punch
PUNCH NUM CNC
25-contact male Sub.D 9-, 15- or 25-contact male Sub.D
connector connector
DCD
RD TD
GND GND
DTR CTS
Signal 25-contact Sub.D (GNT side)
RD 3
DTR 20
GND 7
Connection to FACIT punch
PUNCH NUM CNC
25-contact male Sub.D 9-, 15- or 25-contact male Sub.D
connector connector
DCD
RD TD
GND GND
CTS
DTR
Signal 25-contact Sub.D (FACIT side)
RD 14
GND 25
C.2.2.3 Setting up the Link
Connect the tape reader/punch to a serial line of the CNC.
Start the transfer on the tape reader/punch
(See peripheral device documentation).
