B.3 Profile Geometry Programming (PGP) Errors
B.3.1 The end point is not determined or cannot be computed from the elements in the
blocks
Error No. Meaning of the error
101 PGP: Insufficient data for programming a circle
Circle programmed on two parallel axes (with R / see Error 107)
102 Line programmed by an angle and one coordinate with no way of calculating the other coordinate
106 In G02, G03, programming of the third axis without helical option
107 PGP: Circle programmed by its radius and end point, with the end point separated from the start
point by more than 2 * radius
Circle programmed by X, Z, I K with a start radius different from the end point (20 microns) /
Helical: dimension of 3rd axis missing
Circle programmed on two parallel axes (with I, J, K / see Error 101)
B.3.2 The point of tangency or intersection cannot be computed from the data in two
blocks
Error No. Meaning of the error
110 PGP: Syntax error in the first of two blocks of a PGP entity
111 PGP: Syntax error in the second block of a PGP entity
112 PGP: Line/line intersection in which:
First block starting point = second block end point, or
First line angle = second line angle
113 PGP: The values programmed in the two blocks do not allow determination of an intersection or
tangency point
114 PGP: Intersection or tangency point not determined by ET+, ET-, ES+ or ES-
B.3.3 The points of tangency or intersection cannot be computed from the data in three
blocks
Error No. Meaning of the error
121 PGP: Syntax error in the last of the three blocks of a PGP entity
122 PGP: The first two blocks are non-intersecting lines
123 PGP: The data programmed in the three blocks do not allow determination of the tangent point
124 PGP: Tangent point of the second and third blocks not specified by ET+ or ET-
B.3.4 Fillet or chamfer definition errors
Error No. Meaning of the error
130 Zero displacement in one of the two blocks connected by a fillet or a chamfer
131 Fillet or chamfer programmed in a block including M0, M1 or M2
Programming insufficient in a sequence of blocks, not allowing determination of the end point
135 A chamfer can only connect two straight lines
