REAR PANEL DIAGRAM
The rear panel of the Beatkeeper contains Inputs and Outputs for both Channel One
and Channel Two as well as the jack for the power adapter.
WARNING- Use only the power adapter provided with this unit.
1. Channel INPUTS- Plug the patch cords from your CD players (or turntables) into
these jacks
2. Channel OUTPUTS- Attach the patch cords from these jacks to the Input jacks
of your mixer
3. POWER ADAPTER JACK- Plug the (9V 500 mA) adapter that came with your
Beatkeeper into this jack. Note: plugging in any other power adapter or source
voids the warranty on this unit.
