4001 non-addressable control and indicating equipment
Installation and Service Manual
23
32-0002-r12_2018-09
© 2015 ~ 2018 Ambest Electronics (Ningbo) Co Ltd. All rights reserved.
All specifications and other information shown were current at the date of publication and subject to change without notice.
12. SPECIFICATIONS
12.1. Technical Data
Power Supply 4001-01 4001-02 4001-03
Operating voltage AC (85 ~ 260) V / 50/60 Hz
Mains supply current limit 720 mA @ AC 230 V
Mains supply fuse 4 A / AC 250 V slow blow (20 mm)
Mains supply fault threshold voltage ≤ AC 60 V
Power supply 2.2 A @ DC 28.5 V
Quiescent current (I
min
) 45 mA
Maximum continuous output current (I
a, max
) 0.425 A
Maximum short-duration output current (I
b, max
) 1.3 A
Standby battery maximum capacity (2 × DC 12 V) 7.2 Ah
Maximum battery current draw 1.5 A @ maximum operating temperature
Battery fuse 6 A resettable (electronic fuse)
Battery fault threshold voltage < DC 20 V
Battery fault threshold internal resistance (R
I, max
) 0.5 Ω
Quiescent current 45 m A @ DC 28 V
Detection Zones
Detection zone circuits 2 4 8
Number of connected devices per detection zone circuit 32
Detector zone quiescent current 5 mA
Detector zone alarm current 40 mA 80 mA 160 mA
Detector zone wiring characteristics (max) 40 Ω / 0.47 µF
Detection zone end-of-line capacitor 10 µF / DC 50 V
Manual call point resistor value (470 ~ 689) Ω
Alarm Zones
Alarm zone outputs 1
Alarm zone current 700 mA
Alarm zone end-of-line resistor 100 kΩ
Alarm zone monitoring Open- and short-circuit
Alarm zone voltage (max) DC 27.5 V
Alarm zone fuse 1.1 A resettable (electronic fuse)
Ancillary Outputs
Number of programmable output relays 2
Ancillary fire C/O relay 2 × (1.0 A @ DC 30 V / 1 A @ AC 240 V)
Ancillary fault N/C relay 1.0 A @ DC 30 V / 1 A @ AC 240 V
Auxiliary supply DC (12.0 ~ 28.2) V @ 200 mA
Auxiliary supply at (I
b, min
) DC (19.5 ~ 29.0) V @ 0 mA
Ancillary Inputs
Evacuation start / stop Non-latching, voltage-free
Day / Night mode Non-latching, voltage-free
Remote reset Non-latching, voltage-free
