4001 non-addressable control and indicating equipment
Installation and Service Manual
24
32-0002-r12_2018-09
© 2015 ~ 2018 Ambest Electronics (Ningbo) Co Ltd. All rights reserved.
All specifications and other information shown were current at the date of publication and subject to change without notice.
Miscellaneous 4001-01 4001-02 4001-03
Terminal wiring (0.4 ~ 2.5) mm
2
Operating temperature (0 ~ +50) °C
Operating humidity (0 ~ 95) % RH, non-condensing
Storage temperature (-25 ~ +80) °C
Storage humidity (0 ~ 98) % RH, non-condensing
Dimensions (h × w × d) (402 × 337 × 99) mm
Weight (excluding batteries) 4.0 kg
12.2. Ordering Information
Model 2 Alarm Zone Circuits 4 Alarm Zone Circuits 8 Alarm Zone Circuits
4001-01
— —
4001-02 —
—
4001-03 —
—
12.3. Battery Calculations
Calculate the required battery capacity for the installation using the following formula.
[(I
Q
×t
S
) + (I
A
×t
A
)]×1.2
Where:
I
Q
is the total quiescent current (in amps)
t
S
is the required battery operating time (in hours) when the mains supply is unavailable
I
A
is the total Alarm Condition current (in amps) with all devices operating
t
A
is the required Alarm Condition operating time (in hours) following t
S
For current technical data, refer to the 4001 Control and Indicating Equipment datasheet.
Document number 31-0002.
