e) The list below shows a summary of all the connectors on the basis board with their codes
which are marked next to each connector on the board.
J1 Key pad (only LED-machines)
J2 Piezo-sensors
J3 unused
J4 unused
J5 Wheel guard micro switch
J6 Opto encoder printed circuit board
J7 unused
J8 Potentiometer for Distance and Diameter
J9 Main power supply coming from Motor controller board.
J10 unused
J11 Temperature sensor
J12 Potentiometer 3 outside arm (from BM40)
J13 Boot-Jumper for Service update of the Software
J32 Foot pedal switch (QuickSpan)
f) When removing the basis board from the aluminium plate, please be careful not to bend the
ribbon cable as it can be easily damaged and cause the machine to function improperly.
