Page 26 of 54
15. Service Functions
The information on the service functions can also be found in the instruction manual
DIGITAL WHEEL BALANCERS
Via the function key you get into the menu for service functions to select the basic
settings or change them according to the user’s requirements. The various menu functions from
F1 to F14 can be selected by pressing the +- keys
When you are in the function menu, an „Fn“ is shown on the left side of the digital display. The
chosen function is shown on the right side of the digital display.
Once a particular function is desired, it can be chosen by pressing the function key again
F1 Precision reading of 1 Gram
F2 Zero run
The Zero run is provided to electrically compensate the unbalance of the adaptor or clamping
means.
Whenever the clamping means has been dismounted and replaced a compensation of the
residual unbalance in the adapter and clamping means should be carried out.
Routine:
MACHINES with manual clamping of the wheel
Remove the cones and clamp from the adaptor.
Press the function key to select the function menu.
Use +/- keys to select the Function 2.
Press function key again to activate the function.
Press START to start the run.
The residual unbalance of the adaptor is calculated and saved in the
memory. (This value stays in the memory even after switching off the
power). After the run has finished, the program automatically changes
to normal mode.
MACHINES with QuickSpan:
Attach the pressure cup for steel rims to the clamping sleeve and
activate the QuickSpan
Press the function key to select the function menu.
Use +/- keys to select the Function 2.
Press function key again to activate the function.
Press START to start the run.
The residual unbalance of the adaptor is calculated and saved in
the memory. (This value stays in the memory even after switching
off the power). After the run has finished, the program
automatically changes to normal mode.
