30
It is important to make the antenna connection correctly to ensure the GSM Module
is working and able to send a message.
Connect contact inlet of terminal to remote alarm input of device.
SIM card of GSM network is supplied by the user.
NUVE must be informed in advance regarding to mobile phone numbers to which the
failure message will be sent.
NUVE must be informed in advance regarding to SMS message content which will
be sent.
The cost of SIM card and SMS differs according to the GSM network and will be
covered by the user.
10.2. CO
2
CHANGEOVER UNIT
CO
2
changeover unit replaces CO
2
tank in case of CO
2
shortage while not interrupting
the operation of EC 160. The LEDs on CO
2
changeover unit notifies which tank is in use.
If two CO
2
tanks are empty, user is notified by the red led.
Figure 9
First Tank
Manometer and Led
Second Tank
Manometer and Led
The led is on
when two
tanks are
empty
