NUVE EC 160 - TECHNICAL SPECIFICATIONS; TECHNICAL SPECIFICATIONS TABLE; ACCESSORIES

8
EC 160 CO2 Incubator is designed and manufactured in accordance with
international directives EN 61010-1, EN 61326 and DIN 12880. If the warnings
mentioned in this manual are not considered, NUVE will not be responsible from
their results.
2. TECHNICAL SPECIFICATIONS
2.1. TECHNICAL SPECIFICATIONS TABLE
TECHNICAL SPECIFICATIONS
EC 160
Temperature Range
Ambient Temperature +7°C / 50°C
Temperature Sensor
Pt-100
Control System
N-Smart™ Microprocessor Control System
Temperature Sensitivity
0.1°C
Temperature Distribution (at 37°C)
± 0.3°C
Temperature fluctuation (at 37°C)
±0.1°C
Disinfection temperature
90°C
CO
2
Setting Range
%0.0 - 20.0
CO
2
Set and Display Sensitivity
%0.1
CO
2
Sensor
IR Sensor
CO
2
Sensor / Auto-Zero
Standard – In every 12 minutes
Safety System
Gas expansion thermostat
Chamber Capacity
160 liters
Number of Shelves (std./max)
3 / 8
Power Consumption
1160 W
Power Supply
230 V, 50/60 Hz
Internal Material
Stainless Steel
External Material
Epoxy polyester coated steel
Internal Dimensions (W x D x H) (mm)
500 x 460 x 700
External Dimensions (W x D x H) (mm)
917 x 722 x 905
2.2. ACCESSORIES
2.2.1. FACTORY FITTED ACCESSORIES
EC 160H Cable port (25 mm)
EC 160W N-Smart™ Data monitoring software and RS 232 port
2.2.2. OPTIONAL ACCESSORIES
A 08 142 AlerText™ GSM alarm module (SIM card is not included.)
A 08 143 nUVeRay™ UV light sterilization kit
A 08 144 NuveClean™ Decontamination kit for humidity tray (20 doses)
K 13 009 NuveWarn™ Remote alarm system with 10 m cable
A 08 146 Stacking Adapter
A 08 147 Support Frame
