10.5.1. MOUNTING THE REMOTE ALARM KIT
The remote alarm kit includes an alarm unit and 10
meters of cable with a connector. Connect one side of
the cable to the connector at the back side of the EC
160 and the other side to the alarm unit (See Figure
12).
Mount the remote alarm kit to a wall or board no more than 10 meters away
from the device where it is easily accessible.
10.6. nUVeRay™ UV DISINFECTION KIT
The disinfection kit is used for the disinfection after the work in the
incubator is done. Chamber is disinfected by means of nUVeRay™
after all the shelves, humidity tray and samples removed. Refer
Section 6.3.2 for more detailed information regarding to usage of
NuveRay™.
