Nvidia Jetson AGX Orin Series User Manual

PRELIMINARY INFORMATION
Jetson AGX Orin Series Tuning and Compliance Guide DA-11040-001_v0.7 | 43
Ethernet Compliance Test Guide
This chapter describes the process and steps necessary to check the signal compliance of the
RGMII interface of the Jetson AGX Orin series module.
Table 20 lists the acronyms used in this document and their description.
Table 20. Glossary and Acronyms
Acronym Description
ETHER_QOS Orin SoC Unit containing Ethernet controller
RGMII Reduced Gigabit Media Independent Interface
Table 21 lists some characteristics of the Orin module RGMII interface.
Table 21. Orin RGMII Interface
Controller Interface Bus Width Voltage (V) I/O Clock (MHz)
ETHER_QOS RGMII 4 1.8 Up to 125
Required Equipment
The following equipment is required for the signal measurement process:
 Oscilloscope and Probes
 Software:
• Tool to create traffic on the Orin module RGMII interface (for Transmitter)
• Tool to access register space in Orin. For example, devmem2 or in32/out32 can be
used on Linux and QNX environment, respectively.

Nvidia Jetson AGX Orin Series Specifications

General

Memory	32GB 256-bit LPDDR5
Storage	64GB eMMC 5.1
Networking	10/100/1000BASE-T Ethernet
Dimensions	100 mm x 87 mm
GPU	NVIDIA Ampere architecture with 64 Tensor Cores
CPU	12-core Arm Cortex-A78AE v8.2 64-bit CPU
AI Performance	275 TOPS
Power	15W to 60W
Video Encode	2x 4Kp60 | 8x 1080p60 | 16x 1080p30 (H.265/H.264)
USB	2x USB 2.0
PCIe	PCIe Gen 4
Operating System Support	Ubuntu
