Nvidia SN5600 User Manual

26
•
•
•
•
•
•
Interfaces
The systems support the following interfaces:
10/100/1000Mb Ethernet management interface (RJ45)
USB port (Type A)
RS232 Console port (RJ45)
Reset button
Status and Port LEDs
Lane select LEDs and power button
In order to reviLane select LEDs and LS PBew the full configuration options matrix, refer
toManagement Interfaces, PSUs and Fans
.
Data Interfaces
The data interfaces can be used with QSFP-DD/OSFP modules or transceivers. The full list of
interfaces per system is provided in Speed and Switching Capabilities
.
As detailed in the following table, for additional data interfaces, each QSFP-DD/OSFP port can be
connected with a QSFP-DD/OSFP cable or module to SFP (Dynamix QSA™) adapters, hybrid or split
cables*.
Model Family Ports Maximum Speed
SN5400 64 400GbE (50Gbps/lane)
128 200GbE
256 100GbE
50GbE
25GbE
10GbE
SN5600 64 800GbE (100Gbps/lane)
400GbE
128 200GbE
256 100GbE
50GbE
25GbE
10GbE
The systems offer several high-power ports for optical transceivers that require such support. The
following table specifies each system's ports max power capabilities:
High Power Transceivers Support
Model Family Ports Maximum High Power Support
SN5400 All 64 ports 12W
This document is preliminary and subject to change.

