Nvidia SN5600 User Manual

41
For thermal threshold definitions in Cumulus Linux, seeConfiguring SNMP Trapsin theCumulus
Networks Help Center.
Interface Specifications
Small Form Factors Specifications
NVIDIA switch systems come in a flexible range of form factors - SFP/QSFP, SFP28/QSFP28, SFP56/
QSFP56, SFP-DD/QSFP-DD and OSFP.
All form factors specification documents are available on the Storage Networking Industry
Association (SNIA) Website.
USB Standard Specifications
For the specification documents of all available USB types, please refer to the document library in
the USB Organization Website
.
RJ45 to DB9 Harness Pinout
In order to connect a host PC to the Console RJ45 port of the system, a RS232 harness cable (DB9 to
RJ45) is supplied.
RJ45 to DB9 Harness Pinout

Disassembly and Disposal
Disassembly Procedure
To disassemble the system from the rack:
