O-Two eAdvantage 01EQ3000 - Alarm and Warning Priorities

32
eAdvantage User Manual (15PL1033 Rev. 7, July 2022)
Alarm/Warning priorities with corresponding visual/ audible alarms
Symbol Name
Cell
#
Priority Alarm delay
On Screen
Visual Alarm
Audible Alarm
Sensor
error (U13
and/or U14
sensors
failure)
A High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10
pulses each, repeat
every 7.5 seconds
O
2
No O
2
gas
input
≤ 20 PSI
B High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10
pulses each, repeat
every 7.5 seconds
Low O
2
input
pressure
(45-21 PSI)
B Medium Directly
Solid symbol fl ashing
down with yellow
warning symbol
1 Burst with 3 pulses
each, repeat every
20 seconds
HighO
2
input
pressure
≥ 80 PSI
B High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10 pulses
each, repeat every 7.5
seconds
No N
2
O
gas input
≤ 20 PSI
C High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10
pulses each, repeat
every 7.5 seconds
Low N
2
O
passpaine
(45-21 PSI)
C Medium Directly
Solid symbol fl ashing
down with yellow
warning symbol
1 Burst with 3
pulses each, repeat
every 20 seconds
High N
2
O
input
pressure
≥ 80 PSI
C High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10
pulses each, repeat
every 7.5 seconds
Empty
Battery
High Directly
Solid symbol
with fl ashing red
warning symbol
1 Burst with 10
pulses each, repeat
every 7.5 seconds
Low
Battery
Low N/A
Solid yellow symbol
with fi xed yellow
warning symbol
N/A
