eAdvantage User Manual (15PL1033 Rev. 7, July 2022)
Note: The eAdvantage® mixer is considered a critical device, and its
components considered critical components. Only those individuals
trained in the operation of nitrous oxide/oxygen analgesic gas delivery
systems (and this device) should use this equipment. Thoroughly review
the instruction manual before use.
3.3 Controls, Connections and Indicators
A
Green LED for battery
operation indicator
I Output Connection
B N
2
O Input Connection
J LED Confi rmation Indicator
C Power Input Connection K Control Knob
D USB Connection L Cancel Key
E Alarm Buzzer M Audio Paused Key
F
Green LED indicator for
AC power
N Oxygen Flush Key
G
Orange LED indicator for
battery charging
O Oxygen Input Connection
H
Airway pressure
monitoring port
P LCD Screen
A
B
C
D
E
F
G
H
I
J
K
L
N
O
P
M
