AcquiSuite Ally 12 & 48 User Guide (Rev D)

7 | P a g e

AcquiSuite™ Ally Anatomy

All user connections are made on the circuit board. Connectors are identified by function and include

polarity markers.

Element ID

LCD Display

Navigation

Buttons

Plate

Ground

Serial #

Model #

MAC ID(s)

Voltage

Input 1

Voltage

Input 2

AMC48 mounting plate version shown
