9 BIOM® 5 in Use
Instruction Manual BIOM® 5 (G/55400/0413/en) 15 / 40
Additionally for the BIOM
®
5:
You must insert the drive belt and put on a cable duct. The purpose of the
cable duct is to keep the connecting cable of the drive unit at the BIOM® 5c
(also fits the previous model) away from the unsterile microscope parts. The
cable duct and the drive belt can be steam autoclaved and are conditioned
in the same way as the other BIOM® 5 components.
Install the drive belt. First fasten the cable holder to the
connector
Then fit the other side over the cable.
Fig. 9-5: Installation of the drive belt and cable duct
