Odys PDV 67003 - 12 Specifications

ODYS PDV 67003 DVB-T
60
EN
12 Specifications
TFT display size 17.8 cm (7 inch)
Laser wave length 780/650 nm
Video standard PAL
Frequency range 20 Hz … 20 kHz ± 2.5 dB
Audio S/N ratio  85 dB
Audio distortion/noise  – 70 dB (1 kHz)
Channel separation  70 dB (1 kHz)
Dynamic range  80 dB (1 kHz)
Audio Out
Analogue
Audio Out
Output level: 1.5 V ±
0.2
1.0
;
impedance: 10 k:
Video Out
Video Out
Output level: 1 V
P–P
± 0.1;
impedance: 75 :
Asymmetrically negative
Mains voltage AC 100 … 240 V, 50/60 Hz
Power consumptio < 25 W
Dimensions (without battery
pack)
195 mm x 149 mm x 38.5 mm (L x B x H)
Weight (without battery pack) ca. 820 g
DESIGN AND SPECIFICATIONS SUBJECT TO
CHANGE WITHOUT NOTICE.
Manufactured under licence of Dolby Laboratories. “Dolby”
and the “double-D” symbol are trademarks of Dolby
Laboratories. Confidential, unpublished works. © 1992–
1997 Dolby Laboratories. All rights reserved.
