MENU SYSTEM
VIDEO CADENCE:
This identies the cycling of the signal coming into the Odyssey7 and how it is to be
recorded.
AVAILABLE CADENCES:
PROGRESSIVE/PSF: For video signals structured as True Progressive (p) or
Progressive Segmented Frames (PSF).
INTERLACED: For HD video signals structured as interlaced elds (i). Records a
1080i60 video signal without alteration. Note that some cameras carry progressive
video embedded within an interlaced signal. See 3:2 Pulldown below.
REMOVE 3:2 PULLDOWN (TO 24P): For 24p video signals striped within a 60i signal.
Extracts the 24p video, records it as 1080p24 and discards the excess elds for greater
efciency and smoother post.
TIMECODE SOURCE:
Allows selection for origination of timecode. Note that some video sources do not carry
timecode data and at high frame rates some cameras do not generate timecode. In these
cases the Odyssey7 will generate a Record Run timecode from its internal clock. LTC not
supported when recording ARRIRAW.
AVAILABLE TIMECODE SOURCES:
SDI/HDMI (embedded in incoming signal)
LTC (input from external source to LTC port)
TIME-OF-DAY NDF (Odyssey internal clock, non-drop frame counng)
TIME-OF-DAY DF (Odyssey internal clock, drop frame counng)
SEED/RECORD RUN (Set mecode counter, increments while recording)
AUDIO CHANNELS:
Currently locked to two channels. Future rmware updates will allow up to eight audio
channels.
AUDIO SOURCE:
Allows selection of audio input source.
AVAILABLE AUDIO SOURCES:
SDI/HDMI (embedded in incoming signal)
ANALOG (analog 2-channel input via AUD IN port) - Currently available only for HD
ProRes recording.
RECORD TRIGGER:
Allows selection of record trigger mechanism for Odyssey. Note that some cameras do
not output trigger signals over SDI or HDMI.
AVAILABLE RECORD TRIGGERS
RECORD BUTTON (Tap Record Buon on Upper Toolbar to start/stop recording)
CAMERA (Use camera’s trigger to stop/start recording -- trigger output must be
enabled on camera)
TIMECODE (Use detecon of mecode incremenng to start/stop recording --
Odyssey7 TIMECODE must be set to SDI/HDMI or LTC and mecode source set to
Record Run)
REMOTE (Use the Convergent Design Remote Trigger accessory to start/stop
recording. Currently only available for HD Apple ProRes recording.
