MENU SYSTEM
PROJECT RATE:
Determines playback frame rate from the SSDs. Note that all incoming frames are always
recorded, Project Rate only determines the intended playback speed, which can always
be changed in post. The Project Rate can follow the incoming source frame rate or be set
to a specic rate for faster or slower than real time playback.
FOLLOWS INPUT is the default setting, automatically aligning to the incoming framerate
at speeds 60p and below. At higher incoming frame rates, 100/200p signals have a
default Project Rate of 25p and 120p/240p signals default to 24p. This allows an even
division of frames for smooth playback.
AVAILABLE PROJECT RATES:
FOLLOWS INPUT (default seng)
23.98 FPS
24.00 FPS
25.00 FPS
29.97 FPS
30.00 FPS
48.00 FPS
50.00 FPS
59.94 FPS
60.00 FPS
OUTPUTS MENU
The settings in the OUTPUTS menu allow adjustments to the video and audio outputs of the Odyssey.
The OUTPUTS menu is accessed by tapping ☼ then tapping OUTPUTS.
☼
╚
ODYSSEY
SETUP
OUTPUTS
OUTPUTS MENU OPTIONS
VIDEO PSF OUT
This control available in select modes. On/Off control to switch video outputs from the
Progressive (P) to Progressive Segmented Frames (PSF) signal structure. This improves
compatibility with some third-party equipment.
OVERLAYS
On/Off control to replicate OLED Image Analysis tools display over the image on the SDI
and HDMI outputs.
REC TALLY
On/Off control to activate Tally record status indicator over SDI and HDMI outputs. Tally
appears as a colored bar at bottom of image. Green Tally indicates ready to record and
Red Tally indicates recording in progress.
Congratulations! You are through the ☼ menu. Everything gets easier from here. Please
note that many of these controls are also available in the rest of the Upper Toolbar.
17
