Ofs Obeya - Beam and top rail attachment

17ofs.com imagine a place® 800.521.5381 Assembly instructions
Obeya assembly instructions
Beam
Top of post
5/16-18 x 1 ¾" Bolt
1. Attach beam/ top rail to post mounting bracket using
(2) 5/16-18 x 1 ¾" bolts for each post.
2. Slide bolts into rail from side access cutouts on each side of
extrusion and into extruded screw boss.
3. Thread into post mounting plate and tighten (recommended
ratchet wrench for efficiency)
Beam and top rail attachment
